Light Duty Type

JUNEN expanded metal machine is our pride of the ambitious endeavor of the company to have competitive advantage in the world. Since JUNEN is the machine supplier as well as expanded metal product manufacturer, we are happy to share our experiences and provide technical consultation regarding new construction and expansion of expanded metal production.

JUNEN Expanded Metal Machine satisfies different production requirements by supplying high quality customized machines according to your needs. It can be categorized by working width as 35 ,series , 61 series, 75 series, 125 series, 160 series, 190 series, 260 series and 310 series. The Light duty type includes 35 series, 61 series , 75 series and 125 series, and 190 series. According to material thickness requirement, there are L, H, HB, and HH type for your choice. Please contact us for more details and advices.

JEC machine is equipped with servo drives, PLC and HMI control, to assure the capabilities of producing a wild range of expanded metal products in high speed as well as delivering the high quality of outputs. You can produce either with coil or with single sheet of steel on the same machine.

Inquiry Contact us

Mesh Specifications

Series	Spec		Model
Series	Spec		L	H	HB	HH
35	SWD (mm)		0.5 – 2	-	-	-
	LWD (mm)		1 – 4	-	-	-
	Thickness(mm)	MILD STEEL	0.1 – 0.8	-	-	-
	Thickness(mm)	STAINLESS STEEL	0.1 – 0.5	-	-	-
	Speed		1500		-	-
61	SWD (mm)		1 – 6	2 – 15	-	-
	LWD (mm)		2 – 12	4 – 30	-	-
	Thickness(mm)	MILD STEEL	0.3 – 0.8	0.3 – 1.0	-	-
		STAINLESS STEEL	0.3 – 0.6	0.3 – 0.8	-	-
	Speed		1200	1000	-	-
75	SWD (mm)		1 – 12	4 – 34	-	-
	LWD (mm)		2 – 24	8 – 80	-	-
	Thickness (mm)	MILD STEEL	0.3 – 1.2	1.4 – 2.6	-	-
	Thickness (mm)	STAINLESS STEEL	0.1 – 0.8		-	-
	Strand (mm)		0.3 – 3.0	1.4 – 5.0	-	-
	Speed		1200	600	-	-
125	SWD (mm)		1 – 12	2 – 38	12 - 40	-
	LWD (mm)		2 – 24	4 – 76	30 - 140	-
	T Thickness (mm)	MILD STEEL	0.3 – 1.2	0.5 – 3.0	0.5 – 3.5
	T Thickness (mm)	STAINLESS STEEL	0.3 – 1.0	0.5 – 2.0	0.5 – 2.0
	Speed		900	450	350	-
160	SWD (mm)		6 – 15	12 – 40	12 – 50	12 – 70
	LWD (mm)		10 – 32	30 – 140	30 – 140	30 – 160
	Thickness (mm)	MILD STEEL	0.5 – 2.0	0.5 – 3.2	1.5 – 6.0	1.6 – 9.5
	Thickness (mm)	STAINLESS STEEL	0.5 – 1.5	0.5 – 2.0	1.5 – 4.5	1.6 – 7.5
	Speed		450	260	250	230
190	SWD (mm)		2 - 6		12 – 40
	LWD (mm)		4 - 8		30 – 140
	Thickness (mm)	MILD STEEL	0.3 – 1.0		1.0 – 5.0
	Thickness (mm)	STAINLESS STEEL	0.3 – 0.8		1.0 – 3.6
	Speed		500		250
260	SWD (mm)		10 – 35	12 – 50	12 – 70	12 – 101
	LWD (mm)		25 – 76	25 – 140	30 – 200	30 – 203
	Thickness (mm)	MILD STEEL	0.5 – 3.0	1.0 – 5.0	1.0 – 6.0	1.0 – 8.0
	Thickness (mm)	STAINLESS STEEL	0.5 – 2.0	1.0 – 4.0	1.0 – 5.0	1.0 – 5.0
	Speed			250	230	200
310	SWD (mm)		-	-	10 – 70	12 – 101
	LWD (mm)		-	-	20 – 160	30 – 203
	Thickness (mm)	MILD STEEL	-	-	1.5 – 6.0	3.0 – 8.0
	Thickness (mm)	STAINLESS STEEL	-	-	1.5 – 4.0	3.0 – 6.0
	Speed			-	230	200
